28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment

Name: 28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment
Brand: Jiayao Co., Ltd.
SKU: برج درخت بیونیک
Price: 50.00 USD
Availability: InStock

همه محصولات

برج فولادی زاویه دار 3 پا
(62)

برج فولادی زاویه ای 4 پایی
(82)

برج فولادی لوله دار سه پایی
(63)

برج مونوپول
(75)

برج سیم گاید
(63)

برج نگهبان
(15)

برج درخت بیونیک
(49)

برج انتقال برق
(18)

برج تلسکوپی
(12)

چت IM آنلاین در حال حاضر

28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment

تصویر بزرگ : 28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment

جزئیات محصول:

محل منبع:	چین
نام تجاری:	Jiayao
گواهی:	ISO9001:2008 COC
شماره مدل:	برج درخت بیونیک

پرداخت:

مقدار حداقل تعداد سفارش:	4 تن
قیمت:	US$1400-1600,1-100Tons;US$1000-1200,>=100 Tons
جزئیات بسته بندی:	بسته بندی شده در جعبه های چوبی یا همراه با ورق های گالوانیزه
زمان تحویل:	15 روز
شرایط پرداخت:	L/C، T/T
قابلیت ارائه:	500 تن در ماه

مخاطب حالا حرف بزن

28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment

شرح

نام محصول:	28M Bionic Tree Tower ترکیبی از زیبایی‌شناسی درختان طبیعی	مواد:	ASTM A36 A572 Gr50
مهره و پیچ و مهره:	درجه 8.8/6.8/4.8	گواهی:	ISO9001:2008 COC
ارتفاع:	9-40 متر	استاندارد:	ANSI/TIA-222-G/H/F، EN 1991-1-4 و EN 1993-3-1
سرعت باد:	0 تا 300 کيلومتر در ساعت	استاندارد گالوانیزه:	ASTM A123/ ISO 1461
تاثیر زیست محیطی:	سازگار با محیط زیست	درمان ضد خوردگی:	گالوانیزه داغ
طول عمر:	بیش از 20 سال	جوشکاری:	AWS D 1.1
تایپ کنید:	ساختار درختی مصنوعی	سفارشی سازی:	موجود در رنگ ها و اندازه های مختلف
برنامه:	مناسب برای مناطق شهری و روستایی	نویز عملیاتی:	انتشار کم سر و صدا
محل نصب:	محیط های شهری	محل نصب:	مناطق شهری و مراکز شهرها
مکان:	محیط های شهری
برجسته کردن:	28M bionic tree tower modular construction,bionic tree tower versatile infrastructure,natural tree aesthetics modular tower , bionic tree tower versatile infrastructure , natural tree aesthetics modular tower

28M Bionic Tree Tower combining natural tree aesthetics with advanced modular construction for versatile infrastructure deployment 0

JIAYAO CO., LTD

Bionic tree tower, also known as an artificial tree tower, is an innovative structure designed to replicate the look of natural trees while serving critical infrastructure purposes. Unlike traditional towers that often stand out visually, this tower blends seamlessly into landscapes, making it a preferred choice for areas where aesthetic harmony and functionality are both priorities.

1.Specifications

Design
1. Design Code	ANSI/TIA-222-G/H/F, EN 1991-1-4 & EN 1993-3-1
Structure Steel
2. Grade	Mild Steel	High Tensile Steel
	GB/T 700:Q235B, Q235C,Q235D	GB/T1591:Q355B, Q355C,Q355D
	ASTM A36	ASTM A572 Gr50
	EN10025: S235JR, S235J0,S235J2	EN10025: S355JR, S355J0,S355J2
3. Design Wind Speed	Up to 250 km/h
4. Allowable deflection	0.5 ~1.0 degree @ operational speed
5. Tension strength (Mpa)	360~510	470~630
6. Yield strength (t≤16mm) (Mpa)	355	235
7. Elongation (%)	20	24
8. Impact strength KV (J)	27(20°C)---Q235B(S235JR)	27(20°C)---Q345B(S355JR)
	27(0°C)---Q235C(S235J0)	27(0°C)---Q345C(S355J0)
	27(-20°C)---Q235D(S235J2)	27(-20°C)---Q345D(S355J2)
Bolts & Nuts
9. Grade	Grade 4.8, 6.8, 8.8
10. Standards for mechanical properties
10.1 Bolts	ISO 898-1
10.2 Nuts	ISO 898-2
10.3 Washers	ISO 6507-1
11. Standards for Dimensions
11.1 Bolts	DIN7990, DIN931, DIN933
11.2 Nuts	ISO4032, ISO4034
11.3 Washers	DIN7989, DIN127B, ISO7091
Welding
12. Method	CO2 Shielded Arc Welding & Submerged Arc Welding(SAW)
13. Standard	AWS D1.1
Marking
14. Method of marking of the members	Hydraulic Press Stamping
Galvanizing
15. Galvanization standard of steel sections	ISO 1461 or ASTM A123
16. Galvanization standard of bolts and nuts	ISO 1461 or ASTM A153

Core Structural & Design Features

Tree-Like Appearance: It features artificial trunks, branches, and even leaves made from durable materials like fiberglass or high-strength plastics, closely resembling real trees in shape, color, and texture.
Modular Construction: The tower is built with modular components, allowing customization in height (typically 5m to 30m) and “tree species” to match local flora, such as pine, palm, or oak trees.
Integrated Functionality: Equipped with hidden platforms, antenna mounts, and cable management systems to support telecommunications equipment (5G/4G antennas, microwave devices), environmental sensors, or even small wind/solar energy harvesters.

Key Materials & Manufacturing Standards

Primary Materials: High-quality fiberglass, UV-resistant plastics, and galvanized steel for the internal support structure, ensuring both durability and corrosion resistance.
Manufacturing Compliance: Follows industry standards like ASTM D256 for impact resistance of plastic components and ISO 1461 for galvanization, guaranteeing long-term performance in outdoor conditions.
Aesthetic Details: Leaves and branches are designed to withstand extreme weather (high winds, heavy snow) and maintain colorfastness for years, using advanced pigmentation techniques.

2.Product Detail
